Core features
Sturdy and reliable structure
Made of high-quality cold-rolled steel plates, stainless steel and other materials, it is precisely cut by laser, bent by CNC and formed by high-strength welding. The main load-bearing structure and frame have been mechanically optimized, resistant to vibration and deformation, and suitable for all kinds of harsh environments.
Outstanding heat dissipation management
We offer a variety of ventilation design solutions (including mesh doors, fan installation positions, ventilation covers, air conditioning interfaces, etc.) to effectively enhance the heat dissipation efficiency of equipment operation and ensure that the internal temperature of the cabinet remains stable.
Flexible installation space
Standard 19-inch installation architecture (compatible with EIA-310-D standard), height-adjustable installation rails, flexible depth adaptation, supports integration of various devices such as servers, switches, and UPS, and layer boards and cable management devices can be flexibly configured according to requirements.
Fine surface treatment
The surface undergoes multiple treatments such as degreasing, phosphating, and electrostatic spraying, resulting in a uniform and corrosion-resistant coating. It is available in a variety of colors (commonly RAL7035, etc.) and offers different texture effects such as brushed and frosted.
Humanized design and safety
Equipped with safety locks, transparent glass doors or metal door options, it facilitates operation while enhancing the physical security of the equipment. The top and bottom line entry holes, detachable side plates, pulley blocks, etc. enhance the convenience of deployment and maintenance.
Technical parameters
Material: High-quality cold-rolled steel plate/stainless steel
Thickness: Main frame 1.2-2.0mm, door panel and side panel 0.8-1.5mm
Surface treatment: Degreasing → phosphating → electrostatic spraying (Other protective or decorative processes are optional)
Installation standard: 19 inches, compatible with IEC 60297, ANSI/EIA-310-D
General height: 6U to 47U and many other specifications
Common colors: black, gray, white (customization supported)
Optional accessories: shelves, rails, PDU, cable management frames, fan units, blind plates, etc
Application scenarios
Enterprise network cabinet and server hosting
Packaging of industrial control systems and automated equipment
Telecommunication base stations, transmission equipment and data centers
Integration of power distribution equipment and monitoring systems
Audio-visual broadcasting and installation of multimedia equipment
The services we provide
Customized production: Supports personalized demands such as non-standard sizes, special hole positions, corporate colors, and logo printing.
Integrated manufacturing: The entire line from sheet metal processing, welding, spraying to assembly is independently completed, with quality control running through the entire process.
Professional technical support: Provide cabinet configuration plans, heat dissipation assessment and installation suggestions.
Reliable delivery capability: Strictly deliver on time, balancing quality and efficiency.
