Core features
High protective performance
The surface of the box has undergone anti-rust and anti-corrosion treatment, supporting IP54 and above protection levels (higher levels are optional), effectively preventing dust and splash water, and is suitable for complex environments such as humidity and dust.
Safe and reliable structure
The internal layout is reasonable, with ample installation space. It adopts a layered and zoned design and supports the installation of circuit breakers, leakage protection devices and other components on rails. The box door is designed with a double lock and requires a special tool to open, enhancing operational safety.
High-quality materials and craftsmanship
Box body: Cold-rolled steel plate thickness ≥1.2mm, surface electrostatically sprayed plastic, corrosion-resistant and impact-resistant.
Interior: Galvanized installation plate, with good insulation and reliable grounding.
The door frame is equipped with sealing strips to enhance the sealing performance and protective capacity.
Flexible configuration options
We offer a variety of sizes (such as 300×400×200mm to 800×1000×200mm), single/double door designs, transparent or solid door panels, surfacing/recessed installation types, and can add or delete wire entry and exit holes, install internal hanging components or nameplate markings as required.
Convenient installation and maintenance
The box body is pre-punched with standard module holes, supporting rapid expansion and adjustment. The door panel can be fully opened, facilitating the installation of components and the maintenance of circuits.
Application scenarios
Power distribution systems for residential buildings and office buildings
Public buildings such as shopping malls, hospitals and schools
Factory workshops, computer rooms, and outdoor power distribution equipment
Power distribution support for new energy charging piles
Technical parameters
Rated voltage: AC 230/400V
Rated current: 63A - 630A (depending on configuration)
Protection grade: IP54 (default), IP55/IP65 are optional
Material: Cold-rolled steel plate/stainless steel (optional)
Color: Standard Gray (Custom colors are supported)
Service support
We offer professional technical consultation, drawing design, non-standard customization and after-sales guidance services to ensure that the distribution box is perfectly matched with your power system. Welcome to contact our customer service for detailed information and quotation plans.
